Multi-VLAN Deployment

Scanopy uses daemons to discover hosts and services. For isolated VLANs, you’ll need additional daemons deployed on each network segment.

┌─────────────────────────────────────────────────────────────┐
│                    Scanopy Server                           │
│                   (Cloud or Self-Hosted)                    │
└─────────────────────────┬───────────────────────────────────┘
                          │
        ┌─────────────────┼─────────────────┐
        │                 │                 │
        ▼                 ▼                 ▼
┌───────────────┐ ┌───────────────┐ ┌───────────────┐
│ VLAN 1        │ │ VLAN 2        │ │ VLAN 3        │
│ Production    │ │ IoT           │ │ Guest         │
│ 192.168.1.0/24│ │ 192.168.2.0/24│ │ 192.168.3.0/24│
│ [Daemon 1]    │ │ [Daemon 2]    │ │ [Daemon 3]    │
└───────────────┘ └───────────────┘ └───────────────┘

When You Need Multiple Daemons

One Daemon is Enough When:

• All hosts are on the same subnet as the daemon
• You have a management host with routes to all VLANs
• Your firewall allows the daemon to reach all subnets
• You don’t need MAC addresses from isolated networks

You Need Multiple Daemons When:

• VLANs are isolated by firewall rules
• You need accurate MAC address collection (requires Layer 2 access)
• Different networks have different security requirements

Deployment Strategies

Strategy 1: Daemon Per VLAN (Recommended)

Deploy a lightweight daemon on each VLAN.

Pros: Full Layer 2 access (MAC addresses, ARP), no inter-VLAN firewall rules needed, best discovery accuracy

Cons: More daemons to manage, requires a host on each VLAN

Best for: Production environments, security-conscious deployments

Strategy 2: Central Daemon with Routing

Use a single daemon on a host that can route to all VLANs.

Pros: Single daemon to manage

Cons: No MAC addresses for remote subnets, requires firewall rules, can’t discover hosts without open ports

Best for: Small networks, lab environments, quick setup

Strategy 3: Hybrid Approach

Central daemon for routable networks, dedicated daemons for isolated segments.

Step-by-Step Setup

Step 1: Plan Your Deployment

VLAN	Subnet	Purpose	Daemon Location
1	192.168.1.0/24	Production	Server host
10	192.168.10.0/24	IoT	IoT management VM
20	192.168.20.0/24	Guest	Guest network AP

Step 2: Create Daemon in Scanopy UI

1. Navigate to Manage > Daemons
2. Click “Create Daemon”
3. Select the target network
4. Choose daemon mode:
   • Pull: Daemon polls for work (daemon only needs outbound access to server)
   • Push: Server initiates scans (daemon must be reachable from server)
5. Click “Generate Key”
6. Copy the installation command

Step 3: Deploy Daemon

Follow the installation instructions in Installing a Daemon.

For Docker container discovery on the daemon host, see Docker Socket Proxy.

Step 4: Configure Discovery

1. Navigate to Discover > Scheduled
2. Click “Create Discovery”
3. Select the daemon you deployed
4. Choose Network Scan
5. Select subnets to scan
6. Set schedule or run manually

Step 5: Verify

1. Run a manual discovery from Discover > Sessions
2. Check Manage > Hosts for discovered devices
3. Verify Topology shows hosts from all VLANs

For consolidating hosts that appear on multiple VLANs, see Consolidating Duplicate Hosts.

Network Requirements

Firewall Rules for Pull Mode (Recommended)

Daemon initiates all connections. Minimal firewall changes needed.

Source	Destination	Port	Protocol	Purpose
Daemon	Server	60072	TCP	API communication
Daemon	Local subnet	*	TCP	Network scanning

Firewall Rules for Push Mode

Server initiates scan requests. Daemon must be reachable.

Source	Destination	Port	Protocol	Purpose
Server	Daemon	60073	TCP	Push scan requests
Daemon	Server	60072	TCP	Report results
Daemon	Local subnet	*	TCP	Network scanning
